360° Degree Green Circle Uniform Line Laser Projector 520nm 30mW for Pipeline Inspection and 3D Scanning
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | 360° Green Uniform Line Laser Diode Module | Wavelength | 520nm |
|---|---|---|---|
| Fan Angle | 360 | Line Width | ≤1mm@500mm |
| Operating Voltage | 3-12V DC | Output Power | ≤30.0mW |
| Case Material | Insulated Aluminum Black Anodized | Size | 16x70mm |
| Customized Support | OEM, ODM | Life Span | 10,000 Hours |
| Warranty | 1 Year |
Product Description
360° Degree Circle 520nm 30mW Green Uniform Line Laser Projector for Pipeline Inspect and 3D Scanning
Product Description
AIMLASER provides customized red and green 360-Degree Uniform Line Laser Modules with different output power, line width, and dimensions for industrial applications. The circular line projector can project square, rectangular, circular, or other irregular shapes tailored to specific spatial requirements.
The uniform line laser projector uses a high-quality coated 360° cone lens, delivering a thin, clear, and uniform laser line. The laser intensity, light, and energy are well distributed at the place it is projected. The thinnest line can be 10µm, with wavelengths ranging from 405nm to 850nm. The input voltage is also variable, from 3V to 12V DC.
Our energy-uniformly-distributed line laser generators feature compact size, narrow line width, high stability, and reliability. They are easy to operate, produced in our ISO9001:2008-approved factory, and conform to ROHS, FDA, IEC, and SGS standards. These modules are widely used in 360° pipeline inspections, pipeline defect detection, laser leveling systems, laser alignment and measure instrument, and industrial machine vision 3D scanning etc.
The 520nm 30mW 360° Green Uniform Line Laser Diode Module has an adjustable focus. Please contact us if you require customized solutions.
Specifications
|
ITEMS |
PARAMENTERS |
|
Model Number |
360° Uniform Distribution Line Laser Diode Module |
|
Wavelength |
520nm |
|
Output Power |
≤30mW |
|
Line Width |
≤1mm@500mm |
|
Fan Angle |
360° |
| Input Voltage | 3~12.0VDC |
| Working Current | <120mA |
| CDRH Class | Class IIIb |
| Divergence | 0.3mrad |
| Dimensions | Φ16x70mm |
|
Circuit control |
Auto Constanct Current (ACC) |
|
Circuit Protection |
Static, Surge, and Reverse Polarity Protected |
| Driver Mode | CW, TTL, Analog Modulation, Digital Modulation |
|
Working Temperature |
-10℃ to 50℃ |
|
Storage Temperature |
-40℃ to 80℃ |
|
Material |
Aluminum Black Anodized (Insulation) |
|
Life Time |
≥10,000Hrs |
Features
1. Compact size, narrow line width.
2. High stability and reliability, long lifetime.
4. Using original Laser Diodes from Arima, Osram, Nicha and branded chips.
5. Conform to ROHS, FDA, IEC, SGS standards.
6. Provide one-year warranty and customized solutions.
Applications
520nm 30mW 360° Green Uniform Line Laser Diode Module applications:
● Machion Vision Laser
● Robot Vision 3D Laser Detection Scanner
● Pipeline Inspections
● 360 Laser Scanner
● Pipeline Defects inspection
● Industrial Measurement and Inspection
● Road and Rail Inspection
● structured Light
● Laser Alignment
● Laser Leveling System
● Concentricity Locating
Trade Terms
1) Payment: T/T, PayPal, Western Union, etc.
2) Shipment: FedEx, DHL, UPS etc.
3) Delivery Time: 5 - 20 days.
4) Shipment Terms: FOB Xi'an China
Why Choose Us
A. Over 20 years laser experience.
B. Large-scaled facility 4,500sq.m2 and over 180 professional staffs.
C. Use original LDs from Arima, Osram, Nicha and so on to guarantee reliability.
D. Strictly following ISO9001:2008 quality system.
E. Product conforms to FDA, IEC and GB standard.
F. Strong design and production capabilities, partners of famous brands.narrow line width
